In this project, I aimed to consolidate my Terraform knowledge by demonstrating best practices while provisioning AWS resources. The source code for this project can be found here!

Project Overview

— Architecture

The architecture diagram below illustrates an AWS-EC2 instance running a containerized Nginx server within a VPC, complete with a subnet and an internet gateway. To deploy our application, we need to create the following AWS resources:

1. AWS VPC
2. AWS Subnet
3. AWS Internet Gateway
4. AWS Route Table
5. AWS EC2 Instance
6. AWS Key Pair
7. AWS Security Group

Integration of Resources: The Non-Terraform Way

Create a VPC

1. Navigate to the VPC Dashboard in the AWS Management Console
2. Click on "Create VPC"
3. Specify a CIDR block (e.g., 10.0.0.0/16)
4. Name your VPC and click "Create"

Create a Subnet

1. Navigate to the Subnets section within the VPC dashboard
2. Click on "Create Subnet"
3. Select your VPC, specify a CIDR block (e.g., 10.0.1.0/24), and select an availability zone
4. Name your subnet and click "Create"

Create an Internet Gateway

1. Navigate to the Internet Gateways section in the VPC dashboard
2. Click on "Create Internet Gateway"
3. Name your Internet Gateway and click "Create"
4. Attach the Internet Gateway to your VPC by selecting it and clicking "Actions" → "Attach to VPC"

Create a Route Table

1. Navigate to the Route Tables section in the VPC dashboard
2. Click on "Create Route Table"
3. Select your VPC and name your route table
4. Add a route by selecting the route table, clicking "Routes" → "Edit routes" → "Add route"
5. Specify 0.0.0.0/0 as the destination and your Internet Gateway as the target
6. Associate the route table with your subnet by selecting "Subnet Associations" → "Edit subnet associations" and selecting your subnet

Create a Security Group

1. Navigate to the Security Groups section in the EC2 dashboard
2. Click on "Create Security Group"
3. Name your security group and select your VPC
4. Add inbound rules for HTTP (port 80) and SSH (port 22) with the source type as "Anywhere"
5. Save the security group

Create a Key Pair

1. Navigate to the Key Pairs section in the EC2 dashboard
2. Click on "Create Key Pair"
3. Specify a name for your key pair
4. Download the key pair file (.pem) and save it securely

Launch an EC2 Instance

1. Navigate to the EC2 dashboard
2. Click on "Launch Instance"
3. Select an Amazon Machine Image (AMI) (e.g., Ubuntu)
4. Choose an instance type (e.g., t2.micro)
5. Configure instance details:
   • Select your VPC
   • Select your subnet
   • Enable auto-assign public IP
6. Add storage if needed
7. Add tags to name your instance
8. Configure the security group by selecting the security group you created earlier
9. Select the key pair you created and launch the instance

Connect to Your Instance

SSH into your instance using the key pair file:

ssh -i /path/to/your-key-pair.pem ubuntu@your-instance-public-ip

Install Docker and Run Nginx

Update the package list and install Docker, then pull and run the Nginx container:

sudo docker pull nginx
sudo docker run -d -p 80:80 nginx

The Problem

There are two major problems:

1. Creating resources manually is time-consuming
2. There's a high chance of missing resources or incorrect configurations

The Solution: Terraform (IaC) Way

Terraform provides a wide range of providers that can be used to provision and manage resources on different platforms such as AWS, GCP, Azure, and many others. Providers are plugins that enable Terraform to interact with APIs of cloud platforms, SaaS providers, and other services.

Provisioning Resources Using Terraform

Step 1: Install Terraform

Download and Install Terraform from their official website.

Step 2: Create Project Directory

Create a directory on your system:

mkdir my-terraform-project
cd my-terraform-project
touch main.tf

Step 3: Define the AWS Provider

Create a providers.tf file:

terraform {
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "5.53.0"
    }
  }
}

provider "aws" {
  region     = var.aws_region
  access_key = var.aws_access_key
  secret_key = var.aws_secret_key
}

Step 4: Define Resources

Create a main.tf file where we will define our resources. You can find all the resources here.

resource "aws_vpc" "my-vpc" {
  cidr_block = var.vpc_cidr_block
  tags = {
    Name = "${var.env_prefix}-${var.vpc_name}"
  }
}

resource "aws_subnet" "my-subnet-1" {
  vpc_id            = aws_vpc.my-vpc.id
  cidr_block        = var.subnet_cidr_block
  availability_zone = var.availability_zone
  tags = {
    Name = "${var.env_prefix}-${var.subnet_name}"
  }
}

resource "aws_internet_gateway" "my-igw" {
  vpc_id = aws_vpc.my-vpc.id
  tags = {
    Name = "${var.env_prefix}-my-igw"
  }
}

resource "aws_route_table" "my-route-table" {
  vpc_id = aws_vpc.my-vpc.id
  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.my-igw.id
  }
  tags = {
    Name = "${var.env_prefix}-my-route-table"
  }
}

resource "aws_route_table_association" "my-route-table-association" {
  subnet_id      = aws_subnet.my-subnet-1.id
  route_table_id = aws_route_table.my-route-table.id
}

resource "aws_security_group" "my-sg" {
  name   = "${var.env_prefix}-my-sg"
  vpc_id = aws_vpc.my-vpc.id

  ingress {
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = [var.my_ip]
  }

  ingress {
    from_port   = 8080
    to_port     = 8080
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }

  tags = {
    Name = "${var.env_prefix}-my-sg"
  }
}

resource "aws_key_pair" "my-key" {
  key_name   = var.key_name
  public_key = file("${var.key_path}")
}

resource "aws_instance" "my-ec2" {
  ami                         = data.aws_ami.latest-ubuntu-image.id
  instance_type               = var.instance_type
  subnet_id                   = aws_subnet.my-subnet-1.id
  key_name                    = var.key_name
  vpc_security_group_ids      = [aws_security_group.my-sg.id]
  associate_public_ip_address = true

  user_data = file("setup.sh")

  tags = {
    Name = "${var.env_prefix}-my-ec2"
  }
}

Step 5: Create Supporting Files

variables.tf

Define all the variables used in the configuration:

variable "aws_region" {
  type        = string
  description = "AWS Default Region"
}

variable "aws_access_key" {
  type        = string
  description = "AWS Admin Access Key"
}

variable "aws_secret_key" {
  type        = string
  description = "AWS Admin Secret Key"
}

variable "vpc_cidr_block" {
  type        = string
  description = "CIDR block for the VPC"
}

variable "vpc_name" {
  type        = string
  description = "Name of the VPC"
}

variable "subnet_cidr_block" {
  type        = string
  description = "CIDR block for the subnet"
}

variable "subnet_name" {
  type        = string
  description = "Name of the subnet"
}

variable "availability_zone" {
  type        = string
  description = "Availability Zone"
}

variable "env_prefix" {
  type        = string
  description = "Environment Prefix"
}

variable "my_ip" {
  type        = string
  description = "My IP"
}

variable "instance_type" {
  type        = string
  description = "Instance Type"
}

variable "key_name" {
  type        = string
  description = "Key Pair Name"
}

variable "key_path" {
  type        = string
  description = "Key Pair Path"
}

data.tf

Store data variables fetched from AWS:

data "aws_ami" "latest-ubuntu-image" {
  most_recent = true
  owners      = ["099720109477"]
  filter {
    name   = "name"
    values = ["ubuntu/images/hvm-ssd/ubuntu-*"]
  }
}

outputs.tf

Store output variables:

output "aws_ami_id" {
  value = data.aws_ami.latest-ubuntu-image.id
}

output "public_ip" {
  value = aws_instance.my-ec2.public_ip
}

varvalues.tfvars

variable1-name = "variable1-value"
variable2-name = "variable2-value"

Step 6: Create Setup Script

Create setup.sh for Docker and Nginx installation:

#!/bin/bash
apt-get update
apt-get install -y docker.io

systemctl enable docker
systemctl start docker

docker pull nginx
docker run -d -p 8080:80 --name nginx-container nginx

Step 7: Initialize Terraform

terraform init

Step 8: Plan the Execution

terraform plan -var-file="varvalues.tfvars"

Step 9: Apply the Configuration

terraform apply -var-file="varvalues.tfvars"

Step 10: Verify

Verify the changes on your AWS Account to ensure all the resources were created successfully.

Best Practices

Explore the code available in this repository to understand what Terraform Modules are and how they can be used to make your code more modular. You can compare terraform modules to functions in traditional programming which can be reused by providing different inputs to get different outputs.

Thank you for reading! I hope you learned something from this blog. Do share your thoughts using comments.

Happy Learning!
